asic specification |
| Engine model |
D6114 ZG14B |
| Rated power/speed |
147kW/2200rpm |
| Dimension(LxWxH) |
8932×2625×3470mm |
| Operating weight(Standard) |
16000kg |
|
Performance specification
|
| Travelling speed ,forward |
5、8、11、19、23、38 km/h |
| Travelling speed ,reverse |
5、11、23 km/h |
| Tractive force(f=0.75) |
82KN |
| Max. gradeability |
20% |
| Tire inflation pressure |
260 kPa |
| Working hydraulic pressure |
16 MPa |
| Transmission pressure |
1.3～1.8MPa |
|
Operating specification
|
| Max. steering angle of front wheels |
±50° |
| Max. lean angle of front wheels |
±17° |
| Max. oscillation angle of front axle |
±15° |
| Max. oscillation angle of balance box |
15 |
| Frame articulation angle |
±27° |
| Min. turning radius using articulation |
7.3m |
| Biade |
| Maximum lift above ground |
450mm |
| Maximum depth of cutting |
500mm |
| Maximum blade position angle |
90° |
| Blade cutting angle |
28°—70° |
| Circle reversing rotation |
360° |
| Moldboard width X height |
4270×610mm |
