| Model |
Unit |
XMS30S |
| operating weight |
kg |
3272 |
| static linear load(front/rear) |
N/cm |
125/148 |
| speed |
km/h |
0-10 |
| gradeability in theory |
% |
30 |
| min. turning radius( L/R ) |
mm |
2800/4000 |
| min. ground clearance |
mm |
320 |
| wheel base |
mm |
1800 |
| steering angle |
± ° |
30 |
| swing angle |
±° |
10 |
| vibration frequency |
Hz |
52 |
| vibrating system-max. pressure |
Mpa |
18 |
| steering system-max. pressure |
Mpa |
16 |
| nominal amplitude |
mm |
0.4 |
| centrifugal force |
kN |
27 |
| compacting width |
mm |
1200 |
| drum diameter |
mm |
750 |
| engine model |
|
Detuz F3L2011 |
| rated engine speed |
r/min |
2600 |
| rated engine power |
kw |
22 |
| overall dimensions(length/width/height) |
mm |
2725/1340/3000 |
| rated oil wear |
g/kW.h |
235 |
| hydraulic tank capacity |
L |
55 |
| fuel tank capacity |
L |
80 |
| water tank capacity |
L |
150 |
