| Engine |
Travel System |
| Model |
CUMMINS B5.9-C |
Travel motors |
JEIL, Korea; Variable axial piston motor |
| Type |
Water cooling, turbocharged, empty enter-cooling |
Support roller quantities |
2×7 |
| Carrier roller quantities |
2×2 |
| No. of cylinder |
6 |
Travel shoes |
2×46 |
| Bore and stroke |
102mm×120mm |
Travel speed |
3.3/5.4km/h |
| Displacement |
5.9L |
Drawbar pulling force |
167kN |
| Power output |
112kW/1950rpm |
Grade ability |
70% (35°) |
| Ground clearance |
470mm |
| Hydraulic System |
Cab 锛?/strong>Control |
| Pump |
DOOSAN, Korea |
Cab |
All-weather, sound-suppressed Cab and equipped with a heavy, insulated Floor Mat; Front Window can be opened and slid; 6-direction adjustable Seat; LED display, Automatic monitoring, display and warning; cool & hot Air Conditioner |
| Type |
variable double–piston pump |
| Max. discharge flow |
2×215L/min |
| Max. discharge pressure |
| Boom, arm and bucket |
31.9MPa |
Control |
Two hand levers and two foot pedals for travel Two hand levers for excavating and swing;
Electric rotary-type engine throttle |
| Travel circuit |
31.9MPa |
| Swing circuit |
25.5MPa |
| Control circuit |
3.9MPa |
Boom, Arm 锛?/strong>Bucket |
| Pilot control pump |
Gear type |
Boom cylinder |
120mm×85mm×1285mm |
| Main control valve |
Negative flow control |
Arm cylinder |
135mm×95mm×1490mm |
| Oil cooler |
Air cooled type |
Bucket cylinder |
115mm×80mm×1120mm |
| Swing System |
Refilling Capacities锛?/strong>lubrications |
| Swing motor |
JEIL, Korea |
Fuel tank |
360L |
| Swing motor type |
Axial-piston motor |
Cooling system |
25L |
| Brake |
Hydraulic oil released |
Engine oil |
20L |
| Parking brake |
Hydraulic disc brake |
Hydraulic oil tank |
250L Tank oil level |
| Swing speed |
11.5r/min |
420L Hydraulic system |
| Bucket |
| Type |
Backhoe bucket |
| Bucket capacity |
0.9m3 (SAE) |
| Bucket width |
1230mm |
| Arm Type |
 |
| A |
Max. digging depth |
9281mm |
| B |
Max. dumping height |
6480mm |
| C |
Max. digging height |
6605mm |
| D |
Max. vertical digging depth |
5735mm |
| E |
Max. Depth cut for 2440m(8')Level Bottom |
6404mm |
| F |
Max. digging distance |
9845mm |
| G |
Max. digging radius at ground level |
9671mm |
| H |
Min. swing radius of work equipment |
3500mm |
| Digging Force (ISO6015) Unit: kN |
| Arm length |
2925mm |
| Bucket digging force |
115kN |
| Arm digging force |
92.5kN |
| Arm Type 2925mm |
| A |
Overall length |
9548mm |
I |
Tread |
3360mm |
| B |
Ground contact length (Transportation) |
4947mm |
J |
Track length |
4160mm |
| C |
Overall height(to top of boom) |
3073mm |
K |
Track gauge |
2200mm |
| D |
Overall width |
2800mm |
L |
Track width |
2800mm |
| E |
Overall height(to top of cab) |
2965mm |
M |
Shoe width |
600mm |
| F |
Counter weight ground clearance |
1120mm |
O |
Bonnet height |
2375mm |
| G |
Ground clearance |
470mm |
P |
Revolving frame width |
2726mm |
| H |
Tail swing radius |
2905mm |
Q |
Distance from swivel center to tail |
2853mm |
 |
| Operating Weight and Ground Pressure |
| Operating weight includes basic machine (with boom 5.7m, arm 2.925m, and bucket 0.9m3) |
| Shoe width |
600mm |
| Overall width |
2800mm |
| Ground pressure |
45KPa |
| Operating weight |
20500kg |
